S80S
Ø80mm Xenon Lamp Strobe Light
| Voltage: | DC:12V-24VAC:110V,220V |
| Dimension: | Lens Diameter : Ø80(Approx.)Height : 106 |
| Materials: | Lens-ASHousing-ABS |
| Protection rating: | IP54 |
Product Feature
- Ø80mm xenon lamp strobe signal light
- High efficiency strobe light that offers excellent outdoor visibility and long-distance signal light luminance close to natural light
- Lamp connector fastening structure allows for convenient lamp replacement
- Flashing rate : 60-80 flashes/min
- Ambient operating temperature : -30°C to +50°C
- Protection rating : IP54
- Certificates : CE Compliant
Product Specifications
| Model number | Voltage | Current | Xenon lamp | Certificates | Weight | Color | ||
|---|---|---|---|---|---|---|---|---|
| Spec | Standard | Parts no | ||||||
| S80S | DC12V-24V | Max.490mA | 220V-350V | BGA2120-BBC I type | 47 |  | 0.21kg |  R-Red A-Amber G-Green B-Blue |
| AC110V | 100mA | 0.21kg | ||||||
| AC220V | 90mA | 0.21kg | ||||||
※ DC type model has a free-voltage range of 10V-30V
※ CE compliant: DC12V-24V
Download
PDF Catalogue
Operating Manual
External View Drawing(PDF)
External View Drawing (Auto-CAD)
3D drawing (STEP)
